Migrating Apache Camel 3 to 4: Java 17, Jakarta, and the Components That No Longer Exist

Why this cannot wait indefinitely

Apache Camel 3 is end of life. Its final release was 3.22.4 on 9 March 2025, and Camel's download page now lists only 4.x LTS releases as supported. Camel routes sit directly on untrusted input — file drops, queues, partner endpoints, unmarshalled XML and JSON — so an unpatched Camel is not an internal-only risk even when it is deployed as one.

The hard requirements

From Camel's own 3.x to 4.0 migration guide:

• Java 17. Camel 4 supports Java 17; support for Java 11 is dropped. Estates on Java 8 or 11 have a JVM migration inside the Camel one.
• Jakarta EE namespaces. Camel 4 moved from javax.* to jakarta.*. Every such import in routes, processors, type converters and tests changes.
• Spring Boot 3 / Quarkus 3. Camel Spring Boot is released in lockstep with Camel core, so Camel 4 means Spring Boot 3 — itself a Jakarta migration with its own Spring Framework 6 and Spring Security 6 consequences.
• JUnit 5. All JUnit 4 based camel-test modules were removed. Test suites written against them have to be ported before they can tell you whether the migration worked — which is an uncomfortable ordering problem worth solving first.

Components that were removed

Camel 4 deleted a set of components outright. The migration guide lists each with its alternative, and for several the alternative is “none”. Examples from that list: camel-any23, camel-atlasmap and camel-atmos have no replacement; camel-caffeine-lrucache points to camel-cache, camel-ignite or camel-infinispan; camel-cdi points to Camel Spring Boot or Camel Quarkus.

A removed component with no alternative is not a migration task, it is a redesign. Find these first:

# Every Camel component your build actually resolves
mvn dependency:tree -Dincludes=org.apache.camel \
  | grep -oE 'camel-[a-z0-9-]+' | sort -u > components-in-use.txt

# Every endpoint URI scheme used in routes (Java DSL)
grep -rhoE '(from|to|toD|enrich|pollEnrich)\("[a-z0-9+-]+:' src/main \
  | grep -oE '"[a-z0-9+-]+:' | tr -d '":' | sort | uniq -c | sort -rn

Compare components-in-use.txt against the “Removed Components” table in the migration guide. That comparison is the single highest-value hour in the project.

API changes that break compilation

The migration guide documents a long list. The ones that turn up most in real route bases:

• @Produce(uri = "kafka:cheese") becomes @Produce("kafka:cheese") — the uri attribute was removed from @EndpointInject, @Produce and @Consume.
• @FallbackConverter is replaced by @Converter(fallback = true).
• InOptionalOut was removed from ExchangePattern; use InOut.
• The InOnly and InOut EIPs were removed.
• All asyncCallback methods on ProducerTemplate were removed in favour of asyncSend and asyncRequest.
• getExtension on CamelContext was replaced by getCamelContextExtension.
• The String to java.io.File type converter was removed — code that relied on the implicit conversion now fails at runtime rather than compile time, which makes it the one to grep for.
• In the bean component, class types in method signatures now need .class syntax: method=foo(com.foo.MyOrder.class, true).

Most of these are mechanical. The type-converter removal and the YAML DSL change — the backwards-compatible mode that allowed steps as a child of route, from Camel 3.14 and older, is gone — are the ones that surface late.

Behaviour changes that do not break compilation

These are more dangerous, because nothing fails until production:

• Health checks. The guide notes, for example, that camel-kafka's producer-based health check behaves differently in Camel 4 and ends up disabled — so a readiness probe that passed in Camel 3 may no longer be checking what you think.
• XML serialization of routes now uses a generated serializer in camel-xml-io rather than the JAXB one. Tooling that parses dumped route XML may see different output.
• Third-party client swaps. Several components changed the library underneath them — camel-atom moved from Apache Abdera to RSSReader, camel-box moved from Box SDK v2 to v4 — so component options and edge-case behaviour shift even where the URI does not.

A sequence that works

1. Inventory components and URI schemes. Diff against the removed list.
2. Get to the last Camel 3 LTS (3.22.x) first and clear its deprecation warnings. They are the migration guide in executable form.
3. Port tests to JUnit 5 while still on Camel 3. This is possible, and it means you arrive at Camel 4 with a working safety net instead of rebuilding it mid-flight.
4. Move to Java 17 on Camel 3 so the JVM change is isolated.
5. Then take Camel 4 and Spring Boot 3 together, with the javax to jakarta rewrite. OpenRewrite recipes handle the bulk of the namespace change; Camel ships its own upgrade recipes.
6. Regression-test on real message samples, not synthetic ones. Integration bugs live in the edge cases of real payloads.

And then it starts again

The uncomfortable part: arriving on Camel 4 does not end the problem. Camel supports only its two most recent LTS lines, each for about a year. An integration estate that upgrades every two or three years — which is most of them — will be unsupported again within twelve months of finishing this migration.

That cadence mismatch is what OSSeva addresses: patched builds for Camel 2.x, 3.x and expired 4.x LTS lines, so your upgrade schedule is set by your release calendar rather than by Camel's.
